Absolute Winland BZ1 Remote Buzzer

Winland Remote Buzzer BZ-1

THIS ITEM HAS BEEN DISCONTINUED

Use this remote buzzer to quickly add an audible alarm to the Winland alarm products.

• Dimensions: 4.25 x 2.75 x 0.23″
• Tone: 86 dB
• Operating Temperature: 32 – 122F

Winland Remote Buzzer – Specifications

• Power Requirements: 12VDC @ 4.5mA

24VDC @ 9mA

• Sound Output: 2800 Hz ±15% continuous
• Sound Pressure Level @ 1?? (0.3 m): 12VDC – 90 db
• 24VDC – 95 db
• Operating Temp: -40? to +176?F (-40? to +80?C)
• Dimensions: 4.5 x 2.75 x 0.23?? (11.43 x 6.99 x 0.58 cm)
• Weight: 0.65 lb (0.3 kg)
• Mounting: Standard 1-gang switch mounting box

Winland Remote Buzzer – Included

• 1 – Winland BZ-1 Buzzer

Winland Remote Buzzer – Support and Downloads

• Remote Buzzer
